HDS Refrigerated air dryer
Advantages
1,Low dew point: The pressure dew point can be below 5℃ in standard working conditions and the dew point in the air outlet can reach 15℃ or lower.
2,Highly efficient pre-cooling regenerator: reduce the load of evaporator by increasing outlet temp by 10-15℃ and decreasing inlet temp by 8-12℃
3,Colliding whirlwind air-water separator: air and water can be completely separated at dew point.
4,Good heat bypass valve: balance pressure automatically, reduce the load of the compressor, decrease the power loss, ensure performances of the air dryer even under low temperature.
5,Sensitive pressure protection switch: avoid damage to dryer compressor if any fault.
6,Protective welding: Ensure the inner wall of the copper tube welding point not be oxidized, thus to make a clean refrigerated system and reduce the possibility of ice & dirty block.
7,Name brand components: Panasonic, Cope-land, Tecumseh, Maneurop compressor, Danfoss expansion valve, Saginomiya solenoid valve.
8,15%~20% enlarged condenser: 15-20% bigger condenser ensures the refrigerant being completely liquefied in serious environment.
9,Compact system design to make a smaller size and lighter weight
10,Strict QC: test completely before leaving factory to ensure 100% good products.
Dryer Model | BD-7.5 | BD-10 | BD-15 | BD-20 | BD-30 | BD-50 | BD-75 | BD-100 | BD-150 | BD-200 | |
Flow rate Nm/min | 1.0 | 1.5 | 2.0 | 2.5 | 3.8 | 6.5 | 8.8 | 13.5 | 18 | 23 | |
Conditions Limit | A. 80 B. inlet temperature of the ambient temperature 45 ℃ C. air pressure 10kg / c㎡ (overpressure receive special customized) | ||||||||||
Pressure dew point | 2-5℃(Atmospheric pressure dew point think it was 20 ℃) | ||||||||||
Refrigerant | R~12 | R~22 | |||||||||
Refrigerant compressor motor | 1/4HP | 1/3HP | 1/2HP | 3/4HP | 1HP | 1-1/2HP | 2-1/2HP | 3HP | 4HP | 5HP | |
Power supply | AC 1¢ 220V 50/60HZ | AC 3¢ 380V 50/60HZ | |||||||||
Air vent pipe diameter | 3/4" | 1" | 1" | 1~1/2" | 1~1/2" | 2" | 2~1/2" | 2~1/2" | 3" | 4" | |
Dimensions | Length(mm) | 700 | 700 | 700 | 700 | 1000 | 900 | 1250 | 1250 | 1400 | 1400 |
Width(mm) | 420 | 420 | 420 | 420 | 500 | 500 | 570 | 570 | 630 | 630 | |
Height(mm) | 710 | 710 | 710 | 760 | 850 | 900 | 1010 | 1010 | 1190 | 1240 | |
Approximate weight(kg) | 35 | 42 | 50 | 60 | 80 | 90 | 100 | 115 | 120 | 280 |
